SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery
SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery
SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery

Large Image :  SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery

Product Details:
Place of Origin: QINGDAO CHINA
Brand Name: SANWEIHE
Model Number: SWSF-590
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: negotiable
Delivery Time: 20 working days
Payment Terms: L/C, T/T

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery

Description
Type: Multi-Function Packaging Machine,Packaging Line Voltage: 220V/50HZ
Driven Type: Electric Condition: New
Dimension(l*w*h): (L)5500mm*(W)1250mm*(H)1700mm After-sales Service Provided: Engineers Available To Service Machinery Overseas,Online Support,Video Technical Support
Function: Sealing,Wrapping Application: Food,Chemical,Commodity
Power: 5kw Warranty: 1 Year
Packing Speed: 20-110packs/min Weight: 900kg
Highlight:

High Speed Horizontal Flow Wrapping Machine

,

SWSF 590 Flow Wrapping Machine

,

5kw Automatic Packing Machine

SWSF-590 Horizontal High Speed Automatic Packing Machinery Flow Wrapper



This packaging machine is a kind of horizontal flow packing machinery(Flow Wrapper). The Packing Machinery adopts servo motors, improves the control accuracy, reduces waste.



What Is Horizontal Flow Wrapper (Packing Machinery)?



The drawing below shows a horizontal flow wrapping packing machine:

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 0





The flow wrapping packing machine packages product by wrapping it in film. The flow wrapping packing machine has an infeed conveyor, a film feed assembly, a forming area, a cutting head, and a discharge area. Product is placed on the infeed conveyor. As the infeed conveyor delivers product to the forming area, film is drawn from the film feed assembly into the forming area, where a film tube is formed around the product and a finseal is created. The film tube and the product then are delivered to the cutting head. The cutting head creates the endseals while it cuts apart adjoining wrapped products into individual packages, and delivers the packages to the discharge area. At this time the whole packing process is done.



Constituent Parts of Horizontal Flow Wrapping Packing Machine



The packing machine packages product by wrapping it in film. The packing machine has an in-feed conveyor, a film feed assembly, a forming area, a cutting head, and a discharge area.

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 1

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 2

Application of automatic packaging machine:

Piece-product packaging:

Bread, chocolate enrobed cheese bar, popsicles, cookies, waffles, ice trowels, cotton wool.

Group products packaging:

Waffles, meat chops, soaps, sponges, biscuit with tray etc.

Non-standard products (customization):

Individual spoon, fork, knives, also suit for packing spoons, forks, knife, napkin, toothpick, etc.



Features of the automatic packing machine:

Packing machine is based on PLC controlling, more stable and reliable system with less trouble.

Digital display with package length,speed and temperature adjustableseparately,easy and accurate to use.
Two-way tracking for accurate sealing and cutting fo patterns.
Position shutdown and automatic opening-closing device for longitudinalsealing ,ensuring no harm to the packing films.

Having automatic monitoring function. Any fault reason during operation will be self diagnosed, and showing the solution.

Packing parameter with many products could be set, Drawing out the relevant data from memory and the machine will be operate according to these data.





Packing Samples of the packing machine:

SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 3
SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 4SWSF 590 Horizontal Flow Wrapping Machine High Speed Automatic Packing Machinery 5
